Extreme Gold Depth So how deep can you go? Well, up to 40%* deeper than the GPX series. Old gold fields are new again, thanks to the revolutionary new ZVT technology. Minelab takes you much deeper than ever before! Maximum Gold Sensitivity The incredible sensitivity of the GPZ 7000 with the Super‑D coil gives you the ultimate advantage in the field. Find gold others have missed, from sub-gram gold through to those elusive ‘retirement nuggets’ still out there. Precision Ground Balance Most gold is buried in the mineralized ‘difficult’ ground that many detectors can’t cope with. The GPZ 7000 accurately ‘balances’ and automatically ‘tracks’ to even the most severe ground conditions, with ease. Enhanced Noise Immunity The outstanding noise immunity of the GPZ 7000 enables very smooth and quiet detecting. With 256 Noise Cancel channels, the GPZ 7000 picks up less atmospheric noise. Listen to the gold, not the noise interference! * When compared to the average performance of the GPX 5000 in typical environments. Actual performance depends on prevailing conditions.
Detecting Functions Search Modes Gold Mode - High Yield, General, Extra Deep Ground Type - Normal, Difficult, Severe Noise Cancel Auto and Manual (256 channels) Sensitivity Level (1–20) Volume Range (1–20) Limit (1–20) Threshold Level Level (1–50) Pitch (1–100) Audio Smoothing Off, Low, High Ground Balance Auto and Manual (Quick‑Trak trigger button) Mapping Functions GPS Coordinates DMS (degrees, minutes, seconds), DM (degrees, minutes) Zoom Levels 10x10, 20x20, 100x100 (metres/yards per cell) GeoStore 100 FindPoints, 100 Waypoints, 10 GeoHunts GPS Engine u-blox Neo-7 (56 channels, SBAS: WAAS, EGNOS, MSAS) Physical Specifications Coil (GPZ 14) 14" x 13" Super‑D Configuration with skidplate (waterproof to 1 m/3 ft) Battery Li-Ion Rechargeable Pack (7.2V DC, 72Wh) Audio Output 6.3 mm (¼") non waterproof socket, Wi‑Stream wireless signal transmission Headphones KOSS UR 30 100 ohm with 6.3 mm plug (¼-inch) (non waterproof ) Wireless Audio WM 12 module (14 channels) Connect one or more WM 12 modules Display Full colour LCD (320 x 240 pixels) Detector Weight 3.32 kg (7.32 lb) (Including GPZ 14 coil, skidplate and 72Wh battery) Detector Length Collapsed: 1170 mm (46.1”) Laid flat, packed position: 1304 mm (51.3”) Extended: 1526 mm (60.1”) Laid flat, packed position: 1651 mm (65.0”) Harness PRO‑SWING 45 with additional J‑strut, cross piece and GA 10 Guide Arm Other Key Technologies ZVT, Super-D, GPSi, Wi-Stream, W8 PC Connection USB interface for XChange 2 PC software XChange 2 Software supplied on CD (Windows XP, Vista, 7, 8 compatible) Software Updates GPZ 7000 and WM 12 upgradeable via XChange 2 (with internet connection) Detector Menu Page Navigation (6 Detect pages, 5 Map pages) with built-in Guide Sequences
